ZD-DFJ Computer Bottom-sealing Machine
DATA:2011-04-25

Use:



This machine is applied to sealing and cutting the bottoms of the soft packing bags. It is the choice equipment for processing packing bags

for cold drinks, ice creams, ciscuits,  nuts,  tea,  mineral  water  trade marks and detergents,



This machine is applied to sealing and cutting the bottoms of the soft packing bags. It adopts microcomputer  for  its  controller, frequency

speed governor, photoelectric cells, counter,  auto  thermocontroller, stop at higher level. (an  additional  punch  and  port-tearing  device,

single  fiml  bag  sealing  toll  can  be  assembled  according  to  te customer's needs)

The Function and Characteristic:



1.The computer controls the two step  motor  drags  materials, featuring in stable performance in feeding, free length fixing, photoelectric cells, auto stop at code absence.

2.Master motor with  frequency  speed  governor, making  the tools more stable  in  cutting  and  speeding  up  its  working

3.Auto counter and alarm system

4.Two ironing and one sealing devices, auto control temperature, firm and flat sealing,

5.An additional punch and port-tearing device, single fiml bag sealing toll can be assembled according to te customer's needs

Model number

350

500

Bag-making speed

30-200pcs/min

30-200pcs/min

Bag-makin width

20-350mm

20-500mm

Bag-makin length

30-999mm

30-999mm

Positioning precision

±0.5mm

±0.5mm

Power

3.5KW

4.5KW

Weight

800KG

1000KG

Overall dimensionL×W×H

2900×800×1000mm

2900×950×1000mm

Supply voltage

50Hz 380V/220V

50Hz 380V/220V

三、主要技术参数Main Technical Parameters:
