Use:
This machine is applied to processing the drum plastic film bags like blank ones or colorful ones, i.e. high or lower vest bags(shopping bags, food bags).
The Function and Characteristic:
1.Constant temperature sealing makes the sides more firm, cold tool cuts, which makes the bag port e smoother and flatter.
2.The vest part is punched with a hydraulic cylinder automatically and the waste is also automatically discharged.
3.Microcomputer is adopted for the integral machine in control, and the step moto drags the materials,(servo motor optional)
4.The computer controls the two step motor drags materials, featuring in stable performance in feeding, free length fixing, photoelectric cells, auto stop at code absence. While the photoelectric system controls the storage.
5.Free length fixing, photoelectric cells, accurate, stable, auto stop at code absence, photoelectric system controls the storage.
6.It can produce four lines.
Main Technical Parameters:
型号Model |
SS-600 |
SS-700 |
SS-800 |
制度宽度范围(mm) |
150-260 |
170-300 |
170-340 |
制袋长度范围(mm) |
260-550 |
260-550 |
260-600 |
适用材料 |
HDPE、LDPE |
封切厚度(mm)
|
0.008-0.04 |
生产能力(个/min) |
40-400
30~140
30~140 |
气压量(MPa) |
0.5-0.6
|
总功率(kw) |
5 |
5.5 |
6 |
机器重量(kg) |
1000 |
1050 |
1100 |
外形尺寸(mm) |
5300×1200×1900 |
5300×1300×1900 |
5300×1400×1900 |
