Use:
This sort of machine is suitable for processing various HDPE, LDPE, PP material cylinder-shaped plastic film bags such as self-colored or color printed high and low-pressure T-shirt bag(supermarket handbag), flat bag (garment bag, shoes bag), dispensable packing bag for medicine, sanitary towel bag, etc.
The Function and Characteristic:
1. Constant-temperature electrothermal sealing, electrothermal cutting.
2. The whole machine is controlled by microcomputer, and the material is towed by stepping motor (can collocate serve motor control system)
3. Set length randomly, photoelectrical follow, accurate, stable, and it automatically stops, the feeding adopts photoelectrical control.
4. Randomly set pile number, automatic count, whole book pop-up, automatic reposition, with high automatization.
Main Technical Parameters:
|
Model |
RFRQ-500 |
RFRQ -600 |
RFRQ -700 |
|
Max Bag-making width(mm) |
500 |
600 |
700 |
|
Max Bag-making length(mm) |
999 |
999 |
999 |
|
Bag-making thickness(mm) |
0.005-0.05 |
0.005-0.05 |
0.005-0.05 |
|
Production capability(pcs/min) |
30～130 |
30～130 |
30～130 |
|
General power(kw) |
3.3kw |
3.5 |
3.7 |
|
Weight(kg) |
800 |
850 |
900 |
|
Overall dimension(mm) |
2600×1150×1500 |
2600×1250×1500 |
2600×1350×1500 |
