一、Use:
This
machine is suitable for multi-pocket bag（the
pocket size and quantity can be setted）。
二、Processed The Material:
BOPP、 PP、 PE、PVC, etc.
三、The Function and Characteristic:
1.
Microcomputer control machine, stepping motor (or servo motor) control film
feeding,
2.
Computer set length, Accurate and stable photocell
tracking, Stop automatically when losing the
tracking.
3. Automatically
counting
and alarming once the number arrived.
Also could set automatically
stop working.
4. Two side sealing knife (1PC);
air puncher; adhesive tape facility.
5. Optional device: EPC, etc
四、Main
Technical Parameters:
|
Model
|
500型
|
|
Length of Bag
|
30-480mm
|
|
Width of Bag
|
45-450mm
|
|
Speed of Bag-making
|
30-240pcs/min
|
|
Accuracy of Bag
|
±0.3mm
|
|
Total power
|
4.5kw
|
|
Weight
|
750kg
|
|
Overall dimension
(mm)
|
L
|
4000mm
|
|
W
|
1040mm
|
|
H
|
1300mm
|
REMARKS: The Min. width of bag is according your dimension, but Pls note in the
contract.
