YT6600-61200 Series Six-Colour Flexographic Printing Machine
DATA:2011-05-05





Use

This machine is suitable for printing such packing materials as polyethylene,polyethylene plastic bagglass paper and roll paperetc.And it is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag,vest bag and clothes bag,etc.

Characteristics

1.Easy operation,flexible starting accurate colour register.

2.The meter counter can set printing quantity according to the requirement.Stop the machine automatically at the set quantity or when the material is cut off.

3.Lift and lower the printing plate cylinder manually,It will automatically stir the printing ink after lifting.

4.The printing ink is spread by the knurled cylindder with even ink colour.

5.Reliable drying system coordinated with high-speed rotation,it will automatically break circuit when the machine stops.

6.3600 continuous and adjustable longitudinal register device.
7.The imported frequency control of motor speed adapts to different printing speeds.

8.There are inching/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.



Main Technical Variables:

Model of Machine

YT-6600

YT-6800

YT-61000

YT-61200

Max.Width of Printing Material

600mm

800mm

1000mm

1200mm

Max.Printing With

560mm

760mm

960mm

960mm

Length Range of Printed Product

190-960mm

190-960mm

190-960mm

190-960mm

Max.Diameter of Roll Material

ф450mm

ф450mm

ф450mm

ф450mm

Printing Speed

5~50m/min

550m/min

550m/min

550m/min

Thickness of Plate(Including

 Two-sides Glue Paper)

2.38mm

2.38mm

2.38mm

2.38mm

Total Power

16.55kw

20.5kw

24.5kw

25.8kw

Weight of Machine

3500kg

4200 kg

5000 kg

5500kg

Overall Dimensions(mm)

4200*1600*2400

4200*1800*2800

4200*2000*2800

4200*2200*2800
