Use:
This machine is researched with the Japanese technology, and applies multi tools to smash quickly, continually mix,
heat through kneading and rubbing, cold quickly to have the waste and the sides granulated and then put them into
production. It is the up-to-date plastic recycler for granulation of plastics.
The Function and Characteristic:
1.To recycle the polyvinyl chloride, PS, LD polytene, HD polytene, linear LD polytene, degradable plastic film, and sides, soft plastic film, bags, silks,
tapes, ribbons, sheets, pipes, etc.
2.To smash, granulate, recycle the chemical and fiber materials like polyester fibre, Acrylic fibers, polypropylene fiber, Polypropylene, etc.
3.To smash, mix and color in one processing.
4.To granulate in lower temperature, which won't destroy the construction of the molecules, featuring in production capacity, and lowe energy consumption.
5.Multi-purpose machine can substitute the mixer and drier.
6.Smaller land coverage, simple mechanic construction easy operation, adjustable blade space, easy change of tools.
Main Technical Parameters:
Model |
100 |
150 |
200 |
300 |
Body pot volume |
100 |
150 |
200 |
300 |
Production capability |
30-60 |
60-80 |
90-150 |
200-300 |
Power of main motor |
15 |
18 |
30 |
37 |
Power of pump |
0.125 |
0.125 |
0.3 |
0.3 |
Power of heating |
1.5 |
1.5 |
1.5 |
1.5 |
Weight |
750 |
900 |
1000 |
1200 |
Overall dimension |
1300×600×1300 |
1500×700×1400 |
1800×900×1400 |
2000×1000×1400 |
